Nimble AF1000 4U, 48-Bay All Flash Storage Chassis - No Drives

HP P2000 3.5inch Drive Enclosure SAS IO Module 592262-002 AP844B

The NetApp FAS2240 (and the closely related FAS2220) is a compact, entry-level/mid-range unified storage controller from NetApp’s FAS2000 series, released around 2011–2012. It is a 2U rack-mountable dual-controller system designed for small to medium businesses, remote offices, and departmental deployments.

The FAS2240 / FAS2220 is a unified storage platform that supports both block (iSCSI, FC, FCoE) and file (NFS, CIFS/SMB) protocols in a single system. It comes with dual active/active controllers for high availability and uses ONTAP operating system.

Key hardware characteristics of the FAS2240:

• 2U chassis with 24 × 2.5" SFF or 12 × 3.5" LFF drive bays (model dependent)
• Dual controllers (active/active HA pair)
• Onboard ports: 4 × 1 GbE + 2 × 10 GbE (or 8 Gb FC depending on configuration)
• Expansion: Supports external disk shelves (DS2246, DS4243, etc.)
• Performance: Suitable for light to moderate workloads — virtualization, file sharing, backup targets, small databases, VDI, etc.

The FAS2220 is the lower-end variant with slightly reduced performance and port options compared to the FAS2240, but they share the same chassis and many components.

EMC 110-385-202B-03 Isilon Hybrid H500 Storage System

Foxcoon 7066353 Sparc T5-4 RackMount Rails 2nd :: Alt () Other //

IBM 00KF629 SYSTEM BOARD LGA2011-3 FOR IBM SYSTEM X3550 M5 2nd :: Alt () Other //

EMC 303-364-000A Isilon 2-Port 10GB FC Expansion Card 2nd :: Alt () Other //

The Cisco 03-25641-0600 (also known as UCSB-MRAID12G, UCS VIC 1340 + RAID controller bundle, or FlexStorage 12Gbps SAS RAID Storage Controller) is a modular RAID storage controller designed specifically for Cisco UCS B-Series Blade Servers (particularly B200 M3/M4/M5 generations) and some C-Series rack servers with modular LOM (LAN on Motherboard) and storage options.

This is not a standalone PCIe card but a mezzanine-style FlexStorage module that combines:

• Cisco VIC 1340 (Virtual Interface Card) – dual-port 10GbE + storage connectivity
• LSI SAS 3008/3108-based RAID controller – 12 Gbps SAS-3 with hardware RAID support

It installs into the dedicated mezzanine slot on UCS B200 blade servers (or equivalent C-Series modular slot), providing:

• Dual-port 10GbE networking (via VIC 1340) for high-bandwidth fabric interconnect
• 12 Gbps SAS RAID with up to 8 internal SAS/SATA drive ports (supports RAID 0/1/5/6/10/50/60)
• Integrated supercapacitor cache (no battery) for write-back caching during power loss
• Full Cisco UCS integration with UCS Manager (service profiles, firmware updates, monitoring)

The controller supports MegaRAID firmware from Broadcom/LSI, with Dell EMC UCS branding and validation for seamless UCS blade operation. It was a very common configuration in UCS B200 M4/M5 blades for servers needing both high-speed networking and hardware RAID for internal drives without using a full PCIe slot.

IBM 81Y2911 40mm Fan Module for Flex System Enterprise Chassis

The IBM 01LJ126 is a hot-swap fan module (also listed as fan FRU or cooling module) designed specifically for the IBM Storwize V5000 Gen2 storage systems, particularly the 92F model (24-bay 2.5-inch SFF enclosure) and related expansion units in the V5000 Gen2 family.

This is a high-speed, redundant fan assembly that provides active cooling for the Storwize V5000 Gen2 controller enclosure or expansion enclosure (92F = 2.5" SFF 24-drive canister). The module contains multiple high-RPM fans arranged in a single replaceable tray, with integrated airflow direction optimized for front-to-back cooling in the enclosure.

Key characteristics:

• Hot-swappable design — can be replaced without powering down the enclosure when redundancy is maintained (N+1 fan redundancy typical in V5000 Gen2)
• Built-in fault detection and reporting to the Storwize firmware (via LED status and system alerts in GUI/CLI)
• Tool-less insertion/removal with latch mechanism
• Front-to-back airflow (cold aisle intake, hot aisle exhaust)
• Low acoustic noise profile for data center environments

Failure of a fan module typically triggers:

• Amber fault LED on the module
• Enclosure fault light
• Critical alert in Storwize GUI / CLI / email / SNMP
• Potential thermal throttling or enclosure shutdown if multiple fans fail

Replacement restores full cooling redundancy and prevents overheating of drives, controllers, or cache batteries.

Cisco 800-45806-01 3.5" hard drive tray caddy for UCS C3160/C3260

The IBM 01LJ138 is the official hot-swap drive caddy (also called LFF hard drive tray, carrier, or sled) for 3.5-inch Large Form Factor (LFF) drives in the IBM Storwize V7000 Gen2 (models 2076-524/624/724) and Storwize V9000 systems (and compatible expansion enclosures).

This is a tool-less, hot-swappable drive tray designed to securely hold and mount standard 3.5-inch SAS/SATA HDDs or SSDs into the Storwize V7000 Gen2 or V9000 front drive bays. It features:

• Black plastic/metal construction with a spring-loaded latch
• ESD (electrostatic discharge) protection
• Vibration-dampening mounts to reduce drive wear in dense enclosures
• LED pass-through for drive activity/fault indicators
• Alignment pins/guides for fool-proof insertion into the backplane

The caddy is mandatory for installing or replacing drives in these systems — bare drives cannot be inserted directly. It is the exact same tray used in most IBM Storwize V7000 Gen2 and V9000 enclosures (24-bay LFF or 12-bay LFF configurations).

Failure to use the correct tray (or using a mismatched tray from V7000 Gen1, V5000, or other vendors) can cause:

• Drive not detected
• Backplane connection failure
• Vibration-induced errors
• Improper seating or ejection

This tray is a very common FRU (Field Replaceable Unit) when trays are lost, damaged, cracked, or worn out during drive replacements.
