EATON SC200-00 SYSTEM CONTROLLER

The MRV SFP-DGD-SX-R (also listed as SFP-DGD-SX-R) is a Gigabit Ethernet SFP transceiver module designed for 1000BASE-SX operation over multimode fiber (MMF).

The Cisco SNS-3515-K9 (also known as Cisco Secure Network Server 3515, hardware revision V01) is a 1U rack-mountable appliance purpose-built for Cisco Identity Services Engine (ISE) deployments. It serves as a dedicated physical platform for running Cisco ISE software in medium-to-large-scale enterprise, government, or service provider environments requiring high-performance policy enforcement, RADIUS/TACACS+, profiling, posture assessment, guest access, BYOD, 802.1X, and TrustSec/SGT services.

The SNS-3515-K9 is the mid-range appliance in the Cisco Secure Network Server family (below the high-end SNS-3655/3695 and above the entry-level SNS-3415). It is optimized for ISE 2.0 through ISE 3.x deployments (still supported on current ISE 3.4 as of 2026) and provides dedicated hardware acceleration and reliability for authentication, authorization, accounting (AAA), profiling, and policy services.

Hardware configuration (as shipped):

• CPU: 1 × Intel Xeon E5-2620 v3 (Haswell-EP, 6 cores / 12 threads, 2.4 GHz base, 3.2 GHz turbo, 15 MB L3 cache, 85W TDP)
• Memory: 16 GB DDR4 ECC RDIMM (typically 2 × 8 GB or 4 × 4 GB at 2133 MHz; expandable to 128 GB)
• Storage: 2 × 600 GB SAS HDDs in RAID-1 (mirrored) for ISE OS and logs; optional SSD upgrades
• Networking: 4 × 1 GbE RJ-45 onboard + dedicated 1 GbE management port
• Form Factor: 1U rack server (Cisco-branded rebadged UCS C220 M4 rack server platform)
• Power: Dual redundant hot-swap 650W Platinum PSUs
• Management: Cisco IMC (Integrated Management Controller) – dedicated RJ-45 management port with KVM, virtual media, power control

The appliance is pre-installed with Cisco ISE software (customer downloads the ISE ISO and installs it during initial setup). It is fully validated and supported by Cisco TAC for ISE deployments up to 50,000–100,000+ active endpoints (depending on ISE version, deployment type, and feature usage).

587324-001 HP Smart Array Flash Backed Write Cache FBWC Battery Module

078-000-063 EMC CX4 1200W Standby Power Supply SPS Battery Module 100-809-016

512485-B21 HP iLO Advanced Inc 24x7 Support License Software

3573-F4H IBM System Storage TS3200 Tape Library Express Model F4H

The NetApp 114-00063 (also listed as 114-00063+A0 or X758-R6 in some references) is an 850W (891W peak) AC power supply unit (PSU) designed for the NetApp FAS3000 series controllers, specifically the FAS3140, FAS3160, and FAS3170 systems (and compatible with some FAS3240 configurations).

This is a rear-mounted, hot-swappable redundant power supply that provides 850W continuous output power (up to 891W peak) to the FAS3140/3160/3170 controller enclosure. It is engineered for high-availability storage systems running ONTAP, supporting dual-controller HA pairs with N+1 redundancy.

The PSU accepts universal AC input (100–240V) and delivers multiple regulated DC rails to the midplane for controllers, drives, fans, and I/O modules. It features an integrated cooling fan with front-to-back airflow (matching the FAS3000 chassis direction) and clear LED status indicators (AC OK, DC OK, Fault).

In typical deployments, the FAS3140/3160/3170 uses two PSUs in a redundant configuration — allowing live replacement of a failed unit without downtime.

0952848-01 Dell Xyratex Compellant 12-Bay HB-1235 SAS Storage Disk Array

12R7021 IBM Bulk Power Regulator for P590 P595

12-00136-100-A JNI FibreStar Dual Port Fibre Channel HBA

The Dell 02TRM4 is an enterprise-class 1.8TB SAS hard disk drive (HDD) in 2.5-inch SFF (Small Form Factor) with a 12 Gbps SAS (SAS-3) interface and 10,000 RPM spindle speed. It is an OEM-branded version of the Toshiba AL14SEB18EQ (or equivalent AL14SEB series), certified and rebranded by Dell for use in PowerEdge servers and Dell EMC storage platforms.

This is a high-performance, tier-1 enterprise SAS HDD optimized for low-latency random I/O, high IOPS, and reliable 24×7 operation in demanding workloads such as databases, virtualization, VDI, OLTP, transactional systems, boot/OS volumes, and primary storage tiers where speed and responsiveness matter more than maximum capacity per drive.

The drive features:

• Dual-port SAS for redundancy and multipathing in high-availability configurations
• 128 MB cache buffer for improved burst and sustained performance
• 512e (512-byte emulation / Advanced Format) sector format for broad OS/RAID compatibility
• Advanced rotational vibration safeguards to maintain stability in dense multi-drive enclosures

In Dell deployments, the 02TRM4 is commonly used as a performance tier drive in PowerEdge servers (especially 13G–15G generations: R630/R640/R730/R740 series) and compatible Dell EMC storage arrays. It is a popular replacement or upgrade drive for systems needing high random IOPS alongside SSD tiers for hybrid performance/cost balance.
