DELL POWEREDGE R720XD SERVER 86GB Ram 1x E5-2680

The Cisco SNS-3515-K9 (also known as Cisco Secure Network Server 3515, hardware revision V01) is a 1U rack-mountable appliance purpose-built for Cisco Identity Services Engine (ISE) deployments. It serves as a dedicated physical platform for running Cisco ISE software in medium-to-large-scale enterprise, government, or service provider environments requiring high-performance policy enforcement, RADIUS/TACACS+, profiling, posture assessment, guest access, BYOD, 802.1X, and TrustSec/SGT services.

The SNS-3515-K9 is the mid-range appliance in the Cisco Secure Network Server family (below the high-end SNS-3655/3695 and above the entry-level SNS-3415). It is optimized for ISE 2.0 through ISE 3.x deployments (still supported on current ISE 3.4 as of 2026) and provides dedicated hardware acceleration and reliability for authentication, authorization, accounting (AAA), profiling, and policy services.

Hardware configuration (as shipped):

• CPU: 1 × Intel Xeon E5-2620 v3 (Haswell-EP, 6 cores / 12 threads, 2.4 GHz base, 3.2 GHz turbo, 15 MB L3 cache, 85W TDP)
• Memory: 16 GB DDR4 ECC RDIMM (typically 2 × 8 GB or 4 × 4 GB at 2133 MHz; expandable to 128 GB)
• Storage: 2 × 600 GB SAS HDDs in RAID-1 (mirrored) for ISE OS and logs; optional SSD upgrades
• Networking: 4 × 1 GbE RJ-45 onboard + dedicated 1 GbE management port
• Form Factor: 1U rack server (Cisco-branded rebadged UCS C220 M4 rack server platform)
• Power: Dual redundant hot-swap 650W Platinum PSUs
• Management: Cisco IMC (Integrated Management Controller) – dedicated RJ-45 management port with KVM, virtual media, power control

The appliance is pre-installed with Cisco ISE software (customer downloads the ISE ISO and installs it during initial setup). It is fully validated and supported by Cisco TAC for ISE deployments up to 50,000–100,000+ active endpoints (depending on ISE version, deployment type, and feature usage).

CISCO SPA8000-G4 C0 VOIP 8 PORT IP GATEWAY ethernet x 4, ethernet x 4 2nd : Alt () Other //

51J1788 IBM ISS Proventia ES1500-P Automated Network

3573-F4H IBM System Storage TS3200 Tape Library Express Model F4H

Supermicro SuperWorkstation 4U Rackmount Server 747-16 PN: 7047GR-TRF w/ 2x Intel Xeon E5-2640 v2 8-CORE 2GHz | 64GB RAM | 3x 6GB Asus GTX Geforce Titan Black Video Card PN: GTXTITAN-6GD5 | 10-GIGABIT Ethernet Card PN: CX311A

777430-B21 HP Synergy 3820C 10/20GB Converged Network Adapter

8286-42A IBM S824 Power8 Server

The HP 418663-001 (also known as AE496A or AE496-63001) is a StorageWorks 4/64 SAN Switch Power Pack — a complete 4/64-port 4 Gbps Fibre Channel SAN switch from HP's B-Series (Brocade-based) storage networking portfolio.

This is a high-availability, enterprise SAN switch that provides 64 Fibre Channel ports (32 active ports by default in the "Power Pack" bundle, with the option to license and activate the remaining 32 ports). It is based on Brocade Fabric OS and was designed for mid-size to large Fibre Channel Storage Area Networks (SANs) in the mid-2000s to early 2010s.

Key capabilities:

• 32 active 4 Gbps FC ports (expandable to 64 with additional port licenses)
• High-availability design with redundant power supplies, redundant fans, and non-disruptive firmware upgrades
• Advanced fabric services including zoning, ISL trunking, fabric routing, QoS, and Brocade's Fabric Vision tools (when licensed)
• "Power Pack" designation typically indicates it comes with a bundle of 32 active ports plus redundant power supplies and enhanced software features

It was commonly deployed as an edge switch or small core switch in HP StorageWorks SAN fabrics, connecting servers to storage arrays (HP EVA, XP, 3PAR, etc.) or as part of larger multi-switch fabrics.

HP 654218-001 HP D6000 DISK ENCLOSURE 2nd :: Alt () Other //

Nimble AF1000 4U, 48-Bay All Flash Storage Chassis - No Drives

EMC 110-385-202B-03 Isilon Hybrid H500 Storage System

IBM 00KF629 SYSTEM BOARD LGA2011-3 FOR IBM SYSTEM X3550 M5 2nd :: Alt () Other //

IBM 74Y1749 9179 MHB Center Midplane
