637392-B21 HP PROLIANT BL490C G7 X5675 3.06GHz 96GB RAM 2nd :: Alt () Other //

$254.15 (Ex. GST)

In stock: 1

The HP 637392-B21 is a pre-configured HP ProLiant BL490c G7 server blade (also sold under similar CTO/base part numbers like 637392-B21 or 637393-B21 in some regions) — a half-height, dual-socket blade server from the HP BladeSystem c-Class generation (launched 2010–2011), based on the Intel Xeon 5600 series (Westmere-EP) processors.

This specific configuration includes:

  • CPU: 2 × Intel Xeon X5675 (6 cores / 12 threads each, 3.06 GHz base, 3.46 GHz turbo, 12 MB L3 cache, 95W TDP)
    • Total: 12 cores / 24 threads
  • Memory: 96 GB DDR3 ECC Registered RDIMM (typically 12 × 8 GB DDR3-1333 or 6 × 16 GB DDR3-1333)
  • Form Factor: Half-height (c-Class) blade for HP BladeSystem c3000/c7000 enclosures

The HP ProLiant BL490c G7 is a high-density, virtualization-optimized blade server designed for enterprise data centers, virtualization hosts (VMware ESXi, Microsoft Hyper-V, Citrix XenServer), databases, ERP/CRM, web/application serving, and general-purpose compute workloads in the early 2010s.

It features:

  • Dual Intel Xeon 5600-series processors (Westmere-EP) with Hyper-Threading, Turbo Boost, and Intel VT-x/VT-d
  • Up to 18 DIMM slots (9 per CPU) supporting up to 384 GB DDR3 ECC memory
  • Flexible storage: Up to 2 × 2.5" SAS/SATA hot-plug drives (SFF) with hardware RAID (HP Smart Array P410i controller embedded)
  • Networking: 2 × 1 GbE embedded NICs (Broadcom or Intel-based) + optional mezzanine NICs (up to 2 mezzanine cards)
  • Management: Integrated Lights-Out 3 (iLO 3) with dedicated management port for remote KVM, virtual media, power control, and monitoring

This blade is optimized for dense virtualization — a single c7000 enclosure (10 slots) can host up to 20 BL490c G7 blades, delivering high core/memory density in a compact 10U footprint.

Model / Part Number: 637392-B21 (pre-configured CTO/base)

Server Type: HP ProLiant BL490c G7 (half-height c-Class blade)

Processor: 2 × Intel Xeon X5675 (12 cores / 24 threads total, 3.06 GHz base, 3.46 GHz turbo, 95W TDP each)

Memory: 96 GB DDR3 ECC RDIMM (typically 12 × 8 GB or 6 × 16 GB at 1333 MHz)

Maximum Memory Supported: 384 GB (18 × 32 GB DDR3-1333 ECC RDIMMs)

Storage Bays: 2 × 2.5" SFF SAS/SATA hot-plug (onboard Smart Array P410i controller)

RAID: HP Smart Array P410i (0/1/1+0/5/5+0/10/50 with optional cache)

Networking: 2 × 1 GbE embedded (Broadcom BCM5718 or Intel-based) + up to 2 mezzanine NICs

Form Factor: Half-height blade for HP BladeSystem c3000/c7000 enclosures

Management: iLO 3 (Integrated Lights-Out 3) – dedicated management port with KVM/virtual media

Power & Cooling: Chassis-provided (c3000/c7000 enclosure supplies redundant power and cooling)

Launch Era: 2010–2011 (Westmere-EP generation)

Status (2025–2026): Legacy / End-of-Life – HP ended support for BL490c G7 years ago; no new production

Processors: 2 × Intel Xeon X5675
Cores/Threads per CPU: 6 / 12
Base/Turbo Frequency: 3.06 GHz / 3.46 GHz
L3 Cache: 12 MB per CPU
TDP: 95W per CPU

Total Compute: 12 cores / 24 threads

Memory: 96 GB DDR3 ECC RDIMM (configurable up to 384 GB)
Memory Type: DDR3-1333 (PC3-10600R)
Memory Channels: 3 channels per CPU (6 total)
Bandwidth: ~40–50 GB/s total

Storage Bays: 2 × 2.5" SFF SAS/SATA hot-plug

Onboard RAID: Smart Array P410i (0/1/1+0/5/5+0/10/50 with optional 512MB BBWC)

Networking: 2 × 1 GbE embedded + optional mezzanine cards (e.g., 10GbE, FC, Infiniband)

PCIe Slots: 2 × mezzanine slots (Type I/II) for NICs/HBAs

Management: iLO 3 (remote KVM, virtual media, power control, SNMP)

Operating Temperature: 10°C to 35°C (50°F to 95°F) – chassis-dependent

Dimensions: Half-height blade – fits c3000/c7000 enclosure slots

Weight: ≈5–7 kg (fully configured blade)
