637392-B21 HP PROLIANT BL490C G7 X5675 3.06GHz 96GB RAM 2nd :: Alt () Other //

$254.15 (Ex. GST)

In stock: 1

The HP 637392-B21 is a pre-configured HP ProLiant BL490c G7 server blade — a half-height, dual-socket blade server from the HP BladeSystem c-Class generation (launched around 2010–2011), based on the Intel Xeon 5600 series (Westmere-EP) processors.

This specific configuration includes:

  • Processors: 2 × Intel Xeon X5675 (6 cores / 12 threads each, 3.06 GHz base clock, 3.46 GHz turbo, 12 MB L3 cache, 95W TDP) → Total compute: 12 cores / 24 threads
  • Memory: 96 GB DDR3 ECC Registered RDIMM (typically configured as 12 × 8 GB or 6 × 16 GB DDR3-1333 modules)

The ProLiant BL490c G7 is a high-density virtualization and general-purpose blade server optimized for enterprise data centers running VMware vSphere/ESXi, Microsoft Hyper-V, Citrix XenServer, or bare-metal workloads such as databases, ERP/CRM, web/application serving, file/print services, and test/dev environments.

Key features of the BL490c G7 platform:

  • Dual-socket Intel Xeon 5600-series support (up to 12 cores/24 threads per blade with turbo boost)
  • Up to 18 DIMM slots (9 per CPU) for maximum 384 GB DDR3 ECC memory
  • Internal storage: Up to 2 × 2.5" SAS/SATA hot-plug SFF drives with embedded HP Smart Array P410i RAID controller (0/1/1+0/5/5+0/10/50 with optional cache)
  • Networking: 2 × 1 GbE embedded NICs (Broadcom BCM5718 or Intel-based) + up to 2 mezzanine cards (e.g., 10GbE, Fibre Channel, InfiniBand)
  • Management: Integrated iLO 3 (Integrated Lights-Out 3) with dedicated management port for remote KVM, virtual media, power control, and monitoring
  • Form Factor: Half-height blade — fits HP BladeSystem c3000 (8 slots) or c7000 (16 slots) enclosures

A single c7000 enclosure can host up to 16 BL490c G7 blades, providing high core/memory density in a compact 10U footprint.

Model / Part Number: 637392-B21 (pre-configured base)

Server Type: HP ProLiant BL490c G7 (half-height c-Class blade)

Processors: 2 × Intel Xeon X5675 (12 cores / 24 threads total, 3.06–3.46 GHz, 95W TDP each)

Memory: 96 GB DDR3 ECC RDIMM (configurable up to 384 GB)

Storage Bays: 2 × 2.5" SFF SAS/SATA hot-plug

RAID: HP Smart Array P410i embedded (0/1/1+0/5/5+0/10/50 with optional BBWC)

Networking: 2 × 1 GbE embedded + up to 2 mezzanine NICs

Management: iLO 3 (remote KVM/virtual media/power control)

Form Factor: Half-height blade for HP c3000/c7000 enclosures

Launch Era: 2010–2011 (Westmere-EP generation)

Status (2025–2026): Legacy / End-of-Life — HP ended support years ago; no new production

Processors: 2 × Intel Xeon X5675
Cores/Threads per CPU: 6 / 12
Base/Turbo Frequency: 3.06 GHz / 3.46 GHz
L3 Cache: 12 MB per CPU
TDP: 95W per CPU

Total Compute: 12 cores / 24 threads

Memory: 96 GB DDR3 ECC RDIMM (up to 384 GB max)
Memory Type: DDR3-1333 (PC3-10600R)
Memory Channels: 3 channels per CPU (6 total)
Bandwidth: ≈40–50 GB/s total

Storage Bays: 2 × 2.5" SFF SAS/SATA hot-plug

Onboard RAID: Smart Array P410i (0/1/1+0/5/5+0/10/50 with optional 512MB BBWC)

Networking: 2 × 1 GbE embedded + up to 2 mezzanine slots (Type I/II)

PCIe Slots: 2 × mezzanine (for NICs/HBAs/FC)

Management: iLO 3 (remote KVM, virtual media, SNMP)

Operating Temperature: 10°C to 35°C (50°F to 95°F) – chassis-dependent

Dimensions: Half-height blade – fits c3000/c7000 slots

Weight: ≈5–7 kg (fully configured blade)
