Routers

0493-06-1086 Cisco 877 Router 877

CISCO C819GW-LTE-GA-EK9 819H ethernet x 4, ethernet x 2, serial x 1

C9130AXI-Z Cisco 802.11ac 9130AX Wireless Access Point 802.11. Cannot be added to a new Cisco smartnet agreement.

The Cisco 3745-IO-2FE (also referenced as Cisco Catalyst 3745 2-Port Fast Ethernet IO Controller) is an internal daughtercard / I/O controller that was factory-installed or field-replaceable on the Cisco 3745 Modular Access Router (part of the Cisco 3700 Series routers, launched early 2000s).

Product Description

This small card mounts directly onto the motherboard of the Cisco 3745 router and adds two additional Fast Ethernet (10/100 Mbps) RJ-45 ports (typically labeled FastEthernet0/2 and FastEthernet0/3 in IOS) beyond the two built-in Fast Ethernet ports on the base chassis (FastEthernet0/0 and FastEthernet0/1).

Key points:

• It is not a modular network module (NM), WAN interface card (WIC), or external card — it is an integrated I/O controller soldered or plugged internally.
• Adds basic Layer 2 Ethernet connectivity (10/100 Mbps, full/half-duplex, autosensing) for LAN segments, DMZ, separate VLANs, or connecting to downstream switches/routers.
• Fully integrated with the router's main forwarding engine — supports all standard Cisco IOS Layer 2/3 features on these ports (VLANs, QoS, ACLs, static routing, etc.).
• Commonly seen in Cisco 3745 configurations that needed more than two Fast Ethernet ports without consuming external WIC/NM slots.

Cisco ISR4221/K9 Integrated Services Router, 2x RJ-45-based ports, 1x SFP-based port

The Cisco ISR4331/K9 is a 1U rack-mountable, modular Integrated Services Router from the Cisco ISR 4000 Series (launched 2013–2014). It is a mid-range branch router designed for medium-sized businesses, branch offices, and distributed enterprise WAN edge deployments requiring advanced routing, security, SD-WAN, voice, and application optimization in a compact, high-performance platform.

The ISR4331/K9 is a 3-port Gigabit Ethernet router with modular expansion capabilities. It combines routing, security, voice, and application services into a single 1U chassis. Key features include:

• 3 onboard Gigabit Ethernet RJ-45 ports (GigabitEthernet0/0/0, 0/0/1, 0/0/2) — configurable as LAN or WAN interfaces
• 2 NIM slots (Network Interface Modules) for expansion (e.g., T1/E1, serial, ISDN, LTE, voice, additional Ethernet)
• 1 SM-X slot (Service Module slot) for higher-density modules (e.g., SM-X-72FXS/DID voice module, SM-X-64FXO, UCS-E server blades)
• 1 ISM slot (Internal Service Module) for optional security/acceleration cards (e.g., ISM-VPN)
• Dual redundant power supply bays (default single PSU; optional second for redundancy)
• Redundant hot-swap fans (front-to-back airflow)

It runs Cisco IOS XE with modular software licensing:

• IP Base (default) — basic routing, security, QoS
• Upgradable to Security, UC (Unified Communications), AppX (Application Experience), or full UC license bundles

Common deployment scenarios:

• Branch office WAN router with MPLS/Internet breakout
• DMVPN hub/spoke or GETVPN
• Voice gateway (SRST, CME, CUBE)
• SD-WAN edge (with Viptela vManage/IWAN)
• Application visibility & control (AVC, NBAR2)

The "K9" in the part number indicates the crypto-enabled version (IPsec VPN support).

CISCO SPA8000-G4 C0 VOIP 8 PORT IP GATEWAY ethernet x 4, ethernet x 4 2nd : Alt () Other //

CISCO 47-5380-06 7200 SERIES VXR ROUTER

The Meraki MR32 is a dual-band 802.11ac Wave 1 access point from the Meraki MR series, designed for enterprise indoor Wi-Fi coverage in offices, schools, retail stores, branch locations, healthcare, hospitality, and small-to-medium sites.
