Juniper EX4200-24T 24-Port GbE 8-Port PoE 2-Port 10G XFP Managed Network Switch

$105.40 (Ex. GST)

In stock: 7

The Juniper EX4200-24T is a compact, managed Layer 2/Layer 3 Gigabit Ethernet switch from the EX4200 series. It features 24 x 1GbE RJ-45 ports (with 8 ports supporting PoE), and 2 x 10GbE XFP uplink ports, making it ideal for access layer deployments requiring Power over Ethernet and high-speed uplinks.

This switch delivers wire-speed performance with advanced Junos OS features, including Virtual Chassis technology that allows up to 10 EX4200 switches to operate as a single logical device. It is widely used in enterprise campus, branch offices, and data center top-of-rack environments where PoE is needed for IP phones, access points, or cameras, along with 10GbE uplinks for backbone connectivity.

• 24 x 10/100/1000 Mbps RJ-45 ports (8 with PoE/PoE+)
• 2 x 10 Gigabit XFP uplink ports
• 128 Gbps switching capacity / 95 Mpps forwarding rate
• PoE/PoE+ budget up to 190W (with optional power supply)
• Virtual Chassis stacking (up to 10 switches, 480 Gbps stack bandwidth)
• Junos OS with L2/L3 features (VLANs, QoS, OSPF, RIP)
• Redundant power supply support (external RPS or internal PSU)
• Fanless or quiet fan design (model-dependent)

Model / Part Number: Juniper EX4200-24T (with PoE and 10G XFP)
Interface / Connector Type: 24x RJ-45 (10/100/1000 Mbps, 8 PoE/PoE+) + 2x XFP (10GbE)
Capacity / Speed / Frequency: 128 Gbps switching capacity / 95 Mpps forwarding / 10/100/1000 Mbps + 10GbE
Form Factor: 1RU rack-mountable
Spindle Speed (RPM): N/A (Fixed switch)
Sector Format / Firmware Info: Junos OS / Supports Virtual Chassis, L2/L3, PoE
Power Requirements: Internal PSU / PoE budget up to 190W / Typical 100–200W (configuration-dependent)
