637392-B21 HP PROLIANT BL490C G7 X5675 12G S

The HP 637392-B21 is a pre-configured HP ProLiant BL490c G7 server blade (also sold under similar CTO/base part numbers like 637392-B21 or 637393-B21 in some regions) — a half-height, dual-socket blade server from the HP BladeSystem c-Class generation (launched 2010–2011), based on the Intel Xeon 5600 series (Westmere-EP) processors.

This specific configuration includes:

• CPU: 2 × Intel Xeon X5675 (6 cores / 12 threads each, 3.06 GHz base, 3.46 GHz turbo, 12 MB L3 cache, 95W TDP)
  • Total: 12 cores / 24 threads
• Memory: 96 GB DDR3 ECC Registered RDIMM (typically 12 × 8 GB DDR3-1333 or 6 × 16 GB DDR3-1333)
• Form Factor: Half-height (c-Class) blade for HP BladeSystem c3000/c7000 enclosures

The HP ProLiant BL490c G7 is a high-density, virtualization-optimized blade server designed for enterprise data centers, virtualization hosts (VMware ESXi, Microsoft Hyper-V, Citrix XenServer), databases, ERP/CRM, web/application serving, and general-purpose compute workloads in the early 2010s.

It features:

• Dual Intel Xeon 5600-series processors (Westmere-EP) with Hyper-Threading, Turbo Boost, and Intel VT-x/VT-d
• Up to 18 DIMM slots (9 per CPU) supporting up to 384 GB DDR3 ECC memory
• Flexible storage: Up to 2 × 2.5" SAS/SATA hot-plug drives (SFF) with hardware RAID (HP Smart Array P410i controller embedded)
• Networking: 2 × 1 GbE embedded NICs (Broadcom or Intel-based) + optional mezzanine NICs (up to 2 mezzanine cards)
• Management: Integrated Lights-Out 3 (iLO 3) with dedicated management port for remote KVM, virtual media, power control, and monitoring

This blade is optimized for dense virtualization — a single c7000 enclosure (10 slots) can host up to 20 BL490c G7 blades, delivering high core/memory density in a compact 10U footprint.

The HP 637392-B21 is a pre-configured HP ProLiant BL490c G7 server blade — a half-height, dual-socket blade server from the HP BladeSystem c-Class generation (launched around 2010–2011), based on the Intel Xeon 5600 series (Westmere-EP) processors.

This specific configuration includes:

• Processors: 2 × Intel Xeon X5675 (6 cores / 12 threads each, 3.06 GHz base clock, 3.46 GHz turbo, 12 MB L3 cache, 95W TDP) → Total compute: 12 cores / 24 threads
• Memory: 96 GB DDR3 ECC Registered RDIMM (typically configured as 12 × 8 GB or 6 × 16 GB DDR3-1333 modules)

The ProLiant BL490c G7 is a high-density virtualization and general-purpose blade server optimized for enterprise data centers running VMware vSphere/ESXi, Microsoft Hyper-V, Citrix XenServer, or bare-metal workloads such as databases, ERP/CRM, web/application serving, file/print services, and test/dev environments.

Key features of the BL490c G7 platform:

• Dual-socket Intel Xeon 5600-series support (up to 12 cores/24 threads per blade with turbo boost)
• Up to 18 DIMM slots (9 per CPU) for maximum 384 GB DDR3 ECC memory
• Internal storage: Up to 2 × 2.5" SAS/SATA hot-plug SFF drives with embedded HP Smart Array P410i RAID controller (0/1/1+0/5/5+0/10/50 with optional cache)
• Networking: 2 × 1 GbE embedded NICs (Broadcom BCM5718 or Intel-based) + up to 2 mezzanine cards (e.g., 10GbE, Fibre Channel, InfiniBand)
• Management: Integrated iLO 3 (Integrated Lights-Out 3) with dedicated management port for remote KVM, virtual media, power control, and monitoring
• Form Factor: Half-height blade — fits HP BladeSystem c3000 (8 slots) or c7000 (16 slots) enclosures

A single c7000 enclosure can host up to 16 BL490c G7 blades, providing high core/memory density in a compact 10U footprint.
