WS-X6582-2PA Cisco Catalyst WS-X6582-2PA 2 Port Enhanced FlexWAN Module

$90.95 (Ex. GST)

In stock: 2

WS-X6582-2PA Cisco Catalyst WS-X6582-2PA 2 Port Enhanced FlexWAN Module

Model / Part Number: Cisco WS-X6582-2PA

Series: Catalyst 6500 / 6500-E Series Enhanced FlexWAN Module

Slots: 2 × Enhanced Port Adapter bays (accepts Cisco 7200/7300/7500/7600 series PAs)

Chassis Compatibility: Catalyst 6503-E, 6506-E, 6509-E, 6513-E (and non-E versions with compatible supervisors)

Supervisor Requirements: Sup720, Sup32, Sup720-10G, Sup2T (for dCEF and full performance)

Forwarding Engine: CEF720 (distributed CEF with dCEF-capable supervisor)

Switching Capacity (per module): Up to 48 Gbps (non-blocking when using supported PAs)

Forwarding Rate: Up to 72 Mpps (with dCEF supervisor)

Power Consumption: ≈190–250W (typical full load, varies with installed PAs)

Cooling: Chassis-provided (no onboard fans)

Status (2025–2026): Legacy / End-of-Sale / End-of-Support – Cisco ended support for Catalyst 6500/7600 series years ago; no new production

Market Availability: Refurbished or used pulls from decommissioned 6500/7600 chassis

Common Sources: eBay, Amazon (renewed), Renewtech, ServerSupply, NTC-Tech, AHTech Solutions

Typical Price Range: $150–$500 (refurbished, depending on condition; PAs sold separately)

Port Adapter Bays: 2 × Enhanced PA slots (accepts Cisco 7200/7300/7500/7600 series PAs)

Supported Port Adapters (partial list):
PA-2T3+, PA-2FE-TX, PA-GE, PA-OC3-ATM, PA-T3+, PA-2FE-FX, PA-4T+, PA-8T-V35, PA-MC-T3, PA-4E, PA-8E, PA-A3-T3, PA-POS-OC3, etc.

Switching Fabric Connection: 720 Gbps fabric (CEF720 architecture)

Layer 2 Features: VLANs (4,096), VTP, STP/RSTP/MSTP, EtherChannel (LACP/PAgP), PVST+/RPVST+

Layer 3 Features: Static routing, RIP, OSPF, EIGRP (with PFC/MSFC), HSRP/VRRP/GLBP, VRF-Lite, MPLS

QoS: 8 queues per port, strict priority + WRR/WRED, policing, classification, shaping

ACLs: Large-scale IPv4/IPv6 ACLs (up to 256K entries with Sup720 or higher)

NetFlow: NetFlow v5/v9 support (with Sup720 or higher)

Multicast: Hardware multicast replication, IGMP snooping, PIM-SM/DM/SSM

Power Consumption: ≈190–250W (full load, varies with installed PAs)

Operating Temperature: 0°C to 40°C (32°F to 104°F) – chassis-dependent

Dimensions: Full-height, full-length module (fits Catalyst 6500/7600 slots)

Weight: ≈4.5–5 kg (typical for CEF720 line cards)

Cisco Catalyst WS-X6582-2PA 2 Port Enhanced FlexWAN Module PN:WS-X6582-2PA 2nd :WS-X6582-2PA: Alt () Other //

Cisco Catalyst WS-X6582-2PA 2 Port Enhanced FlexWAN Module PN:WS-X6582-2PA 2nd :WS-X6582-2PA: Alt () Other //

$90.95 (Ex. GST)

$90.95 (Ex. GST)
