005051836 EMC 4TB 7.2K 12G SAS HDD Hard Disk Drive For data domain DS60

$105.40 (Ex. GST)

In stock: 7

005051836 EMC 4TB 7.2K 12G SAS HDD Hard Disk Drive For data domain DS60

Model / EMC Part Number: 005051836

Alternate / Cross-References: 118000194 (related Data Domain internal/reference)

OEM Drive Model: Hitachi Ultrastar DC HC310/HC320 series (likely HUH721404ALE600 or equivalent)

Drive Type: Enterprise nearline SAS HDD

Capacity: 4 TB (usable ≈3.64 TiB after formatting)

Interface: SAS 12 Gbps (SAS-3, dual-port)

Form Factor: 3.5-inch LFF (standard 26.1 mm height)

Spindle Speed: 7,200 RPM

Cache: 256 MB (typical for this generation)

Sector Format: 512e (Advanced Format)

Primary Use: Capacity disk in Data Domain DS60 expansion shelf (60-bay enclosure)

Status (2025–2026): Legacy / End-of-Life – Data Domain DD series and DS60 reached EoL/EoS years ago; no new production or active Dell EMC support

Capacity: 4 TB

Interface: SAS 12 Gbps (dual-port, backward compatible with 6 Gbps)

Spindle Speed: 7,200 RPM

Cache Buffer: 256 MB

Sector Format: 512e (Advanced Format)

Sustained Sequential Transfer Rate: Up to ~180–210 MB/s (outer to inner zones)

Average Seek Time: ≈8.0–8.5 ms (read/write)

Rotational Latency: ≈4.17 ms

Average Latency: ≈12–13 ms

Random Read/Write IOPS (typical 4K QD32): ≈150–200 IOPS read / ≈130–180 IOPS write (HDD-limited)

MTBF: 2.0–2.5 million hours (enterprise rating)

Power Consumption: Idle ≈5–6 W / Active ≈8–10 W

Acoustics: ≈2.8–3.4 Bels (idle/seek) – acceptable for data center

Vibration Tolerance: Enhanced rotational vibration safeguards for dense 60-bay enclosures

Operating Temperature: 5°C to 60°C (drive operating range)

Form Factor: 3.5-inch LFF (26.1 mm height) with Data Domain DS60 hot-swap carrier/tray

Carrier Type: Data Domain-specific 3.5" tray (black plastic/metal with latch)

005051836 EMC 4TB 7.2K 12G SAS HDD Hard Disk Drive For data domain DS60 2nd :118000194: Alt () Other //

005051836 EMC 4TB 7.2K 12G SAS HDD Hard Disk Drive For data domain DS60 2nd :118000194: Alt () Other //

$105.40 (Ex. GST)

$105.40 (Ex. GST)
