X342A-R6 Netapp 1.2TB 10K 2.5" 12Gbps 12G SAS Hard Drive HDD Hard Disk

$83.30 (Ex. GST)

In stock: 1

The NetApp X342A-R6 (also cross-referenced with OEM Seagate part ST1200MM0129) is an enterprise-class 1.2TB SAS hard disk drive (HDD) in 2.5-inch SFF (Small Form Factor) with a 12 Gbps SAS (SAS-3) interface and 10,000 RPM spindle speed.

This is a high-performance, tier-1 enterprise SAS HDD from Seagate’s Enterprise Performance 10K HDD family (specifically the ST1200MM0129 model from the v7/v8 series), rebranded and fully certified by NetApp for use in FAS/AFF storage systems, E-Series, and other NetApp platforms.

It is optimized for low-latency random I/O, high IOPS, and reliable 24×7 operation in demanding workloads such as databases, virtualization, VDI, OLTP, transactional systems, boot/OS volumes, and primary/performance storage tiers where speed and responsiveness matter more than maximum capacity per drive.

The drive features:

  • Dual-port SAS for redundancy and multipathing in high-availability configurations
  • 256 MB cache buffer for improved burst and sustained performance
  • Advanced rotational vibration safeguards to maintain stability in dense multi-drive shelves
  • 512e (512-byte emulation / Advanced Format) sector format for broad OS/RAID compatibility

In NetApp deployments, the X342A-R6 is commonly used as a performance tier drive in FAS/AFF hybrid arrays, E-Series storage, or as a replacement/spare in 2.5" disk shelves (DS224C, DS2246, etc.) — especially in configurations needing high random IOPS alongside higher-capacity NL-SAS drives.

Model / NetApp Part Number: X342A-R6

OEM Drive Model: Seagate ST1200MM0129 (Enterprise Performance 10K HDD v7/v8)

Drive Type: Enterprise performance SAS HDD

Capacity: 1.2 TB (usable ≈1.09 TiB after formatting)

Interface: SAS 12 Gbps (SAS-3, dual-port)

Form Factor: 2.5-inch SFF (15mm z-height)

Spindle Speed: 10,000 RPM

Cache: 256 MB

Sector Format: 512e (Advanced Format)

Primary Use: Performance tier storage in NetApp FAS/AFF, E-Series, and compatible shelves

Status (2025–2026): Legacy / End-of-Life – still supported in older FAS/AFF systems but no new production

Capacity: 1.2 TB

Interface: SAS 12 Gbps (dual-port, backward compatible with 6 Gbps)

Spindle Speed: 10,000 RPM

Cache Buffer: 256 MB

Sector Format: 512e (512-byte emulation / Advanced Format)

Sustained Sequential Transfer Rate: Up to ~220–250 MB/s (outer to inner zones)

Average Seek Time: ≈3.8–4.2 ms (read) / ≈4.2–4.6 ms (write)

Rotational Latency: ≈3.0 ms

Average Latency: ≈6.8–7.2 ms

Random Read/Write IOPS (typical 4K QD32): ≈200–250 IOPS read / ≈180–220 IOPS write (HDD-limited)

MTBF: 2.0 million hours (enterprise rating)

Power Consumption: Idle ≈5–6 W / Active ≈8–10 W

Acoustics: ≈3.0–3.6 Bels (idle/seek) – acceptable for data center

Vibration Tolerance: Enhanced rotational vibration safeguards for dense enclosures

Operating Temperature: 5°C to 60°C (drive operating range)

Form Factor: 2.5-inch SFF (15mm height) with NetApp hot-swap carrier/tray

Carrier Type: NetApp-specific 2.5" tray (black plastic/metal with latch)
