NetApp X357A 3.8TB SAS 12G SFF SSD

$736.10 (Ex. GST)

In stock: 1

The NetApp X357A (also listed as NetApp 3.8TB SAS 12G SFF SSD in many reseller and documentation references) is an enterprise-class 3.8TB SAS solid-state drive (SSD) in 2.5-inch Small Form Factor (SFF, 15mm z-height) with a 12 Gbps SAS (SAS-3) interface.

This is a high-capacity, read-intensive / mixed-use SAS SSD from NetApp's validated drive portfolio, typically an OEM-branded version of the Seagate Nytro 3332 or 3331 series (common OEM model ST3840FM0078 or similar), optimized for high IOPS, low latency, and reliable 24×7 operation in demanding storage workloads.

It is designed for use as a performance tier, cache drive, metadata acceleration, or general-purpose SSD in NetApp FAS/AFF hybrid and all-flash arrays, providing significantly faster random read/write performance than 10K/15K HDDs while offering much larger capacity than earlier 1.6TB–1.92TB SAS SSDs.

Key features include:

  • Dual-port SAS for redundancy and multipathing in high-availability configurations
  • Power-loss protection (PLP) via onboard capacitors to flush in-flight writes during power loss
  • Advanced ECC and end-to-end data protection for enterprise-grade integrity
  • Large DRAM cache for excellent burst performance
  • 512e (512-byte emulation / Advanced Format) sector format for broad compatibility

In NetApp deployments, the X357A is commonly used in FAS/AFF hybrid nodes (e.g., FAS8300, FAS8700, FAS9000 series) and all-flash AFF systems (e.g., AFF A-series) — particularly in 24-drive or 48-drive 2.5" shelves (DS224C, NS224) — for high-performance tiers, caching, or replacing smaller SSDs in existing arrays

NetApp Part Number: X357A (primary ordering part)

OEM Drive Model: Seagate Nytro 3332 / 3331 series (typically ST3840FM0078 or equivalent)

Drive Type: Enterprise SAS SSD – Read-Intensive / Mixed-Use

Capacity: 3.8 TB (usable ≈3.45–3.5 TiB after formatting and over-provisioning)

Interface: SAS 12 Gbps (SAS-3, dual-port)

Form Factor: 2.5-inch SFF (15mm z-height)

NAND Type: TLC or enterprise MLC (high-endurance variant)

Primary Use: Performance tier, cache, or general-purpose SSD in NetApp FAS/AFF arrays

Status (2025–2026): Legacy / Still Supported – compatible with current ONTAP but no new production of this exact model

Capacity: 3.8 TB

Interface: SAS 12 Gbps (dual-port, backward compatible with 6 Gbps)

Sequential Read Speed: Up to ~1,100–1,200 MB/s

Sequential Write Speed: Up to ~1,000–1,100 MB/s

Random Read IOPS (4K QD32): Up to ~190,000–220,000 IOPS

Random Write IOPS (4K QD32): Up to ~80,000–120,000 IOPS (mixed-use profile)

Endurance: ~1–3 DWPD over 5 years (typical ~2,000–3,500 TBW)

Power Loss Protection: Yes (capacitor-backed cache flush)

Cache Buffer: Onboard DRAM + flash management

Sector Format: 512e (Advanced Format)

MTBF: ~2 million hours (enterprise rating)

Power Consumption: Idle ≈2–3 W / Active ≈6–9 W

Acoustics: Silent (no moving parts)

Operating Temperature: 0°C to 70°C (commercial grade)

Form Factor: 2.5-inch SFF (15mm height) with NetApp hot-swap carrier/tray

Carrier Type: NetApp-specific 2.5" tray (black plastic/metal with latch)
